Overrun brake Knott KFGL35-A 3500 kg with jockey wheel bracket

Knott KFGL35-A overrun brake, 3500 kg, with jockey wheel bracket

Jockey bracket built in
Rated to 3500 kg
Fits Knott couplings

The Knott overrun brake KFGL35-A is a mechanical overrun device for braked trailers with a maximum authorised mass of 3500 kg. This overrun brake is used in the trailer braking system and transfers the movement from the drawbar to the...

Product details

Overrun brake Knott KFGL35-A
V drawbar mounting
Cast ball coupling
With jockey wheel bracket
Maximum authorised mass 3500 kg
Weight range 2700–3500 kg
Top mounting
Always check that the maximum authorised mass, mounting and compatibility correspond before installation

Overrun brake Knott KFGL35-A 3500 kg for trailer

The Knott overrun brake KFGL35-A is a mechanical overrun device for braked trailers with a maximum authorised mass of 3500 kg. This overrun brake is used in the trailer braking system and transfers the movement from the drawbar to the wheel brakes during braking.

Overrun brake in trailer braking system

When the trailer is pushed forward towards the towing vehicle during braking, the overrun brake is activated and the force is transferred through the brake mechanism to the trailer wheel brakes. During service, the components of the braking system should be checked regularly and worn parts replaced to ensure that the trailer brake functions correctly.
