Lifting eye Bolt, DIN580, WLL 80Kg, M6
DIN580 lifting eye bolt, M6, WLL 80 kg
- Working load limit (WLL) 80 kg
- DIN580 lifting eye bolt
- Round lifting eye
Lifting eye bolt to DIN580 with an M6 thread and a maximum load of 80 kg. The eye is a closed round ring, and across this range the thread size and the rating go together.
Read more about the productProduct details
- M6 thread with a maximum load of 80 kg — the smallest of the DIN580 eye bolts in this range, which goes up to M36 at 5100 kg
- Standard designation DIN580
- Closed round eye, circle ring type
- Do not load the eye bolt above the stated maximum load of 80 kg
Lifting eye bolt DIN580 M6 for trailer
Lifting eye bolt to DIN580 with an M6 thread and a maximum load of 80 kg. The eye is a closed round ring, and across this range the thread size and the rating go together.
Eye bolts as a lifting point
An eye bolt carries its own thread, so it makes a lifting or anchor point where there is none; where a thread is already in place, the eye nut version in this range is DIN582. The stated maximum load applies to the eye bolt itself - in a complete assembly the lowest rated part sets the limit. Seat the eye fully against the surface, keep the pull in line with it, and replace the bolt if the eye or the thread is damaged.
Specifications (5)
| Spare part for | Valeryd |
|---|---|
| Max load (kg) | 80 |
| Thread size | M6 |
| Tube type | DIN580 |
| Ring type | Circle ring |
